Cold Insulation Materials
Our materials choices expertise in all temperature ranges and dimensions, cold stores, cryogenic applications and projects under extreme climatic conditions
POLYETHYLENE INSULATION
Armaflex® FRV
|
Material/ Performance Criteria |
Peak heat release rate (KW) |
Total heat release (MJ) |
Total smoke release (SQM) |
Extent of flame above pipe chase (M) |
| Pass criteria | ≤ 300 | ≤ 83 | ≤ 500 | ≤ 0.3 |
| Armaflex FRV | ✓ | ✓ | ✓ | ✓ |
Armaflex® NH
|
Material Type |
Colour |
Insulation Application |
Temperature Range |
Practical Fire Behaviour |
|
Elastomeric foam based on synthetic rubber |
Dark grey |
Pipes Air Ducts Vessels |
Max. +110℃ Min. -50℃ |
Self-extinguishing Does not drip Does not spread flames |
POLYISOPCYANURATE INSULATION
Corafoam® PIR Foam
|
Corafoam® |
Density |
Insulation Application |
Temperature Range |
Fire Reaction |
|
U 150 F |
240 kg/m3 |
Pipes Ceiling/Roof Wall |
Max. +100℃ Min. –200℃ |
FAR 25.853A 60”/12” Passed |
|
U 200 |
320 kg/m3 |
✓ |
Max. +80℃ Min. -200℃ |
DIN 4102- B3 Class |
|
U 310 |
490 kg/m3 |
✓ |
Max. +80℃ Min. -200℃ |
DIN 4102- B3 Class |
Thermobreak® Thermo Insulation
Thermobreak® Tube – Pipe Insulation
| Material | Density | Noise Reduction Coefficient (ISO 354) | Temperature Range |
Thermo Conductivity (ASTM C518) |
| Physically crosslinked closed cell polyolefin foam with reinforce aluminium foil | 25 kg/m3 | 12mm – 25mm |
Min. -200℃ Max. +100℃
|
0.032 W/m.K |
Foamglas® Industrial Pipe & Equipment Insulation
FOAMGLAS® ONE™ Insulation ASTM C552 Grade 6 by Pittsburgh Corning
|
Material |
Density |
Block Dimensions |
Temperature Range |
|
Lightweight rigid material composed of millions of completely sealed glass cells |
115 kg/m3 |
450mm W x 600mmL 40-180mm Thickness |
Min. -268℃ Max. +482℃
|
